Code Code Codice Code Código |
Pressure Druck Pressione Pression Presión |
F=UNF/UN Thread • Gewinde Filetto • Filetage Rosca |
F1=NPT Thread • Gewinde Filetto • Filetage Rosca |
L1 |
L2 |
D |
D1 |
Ch |
|
292.04.02I |
315 |
7/16" - 20 |
1/8" - 27 |
23 |
20 |
4,5 |
4 |
11 |
|
292.04.04I |
315 |
7/16" - 20 |
1/4" - 18 |
28,5 |
26,5 |
4,5 |
4,5 |
14 |
|
292.05.04I |
315 |
1/2" - 20 |
1/4" - 18 |
27 |
28 |
7 |
6 |
14 |
|
292.05.06I |
315 |
1/2" - 20 |
3/8" - 18 |
29 |
31 |
10 |
6 |
19 |
|
292.06.04I |
315 |
9/16" - 18 |
1/4" - 18 |
27 |
25 |
7,5 |
7,5 |
14 |
|
292.06.06I |
315 |
9/16" - 18 |
3/8" - 18 |
27 |
27 |
8,5 |
7,5 |
14 |
|
292.08.06I |
315 |
3/4" - 16 |
3/8" - 18 |
31 |
29,5 |
10 |
10 |
19 |
|
292.08.08I |
315 |
3/4" - 16 |
1/2" - 14 |
31 |
34 |
10 |
10 |
19 |
|
292.10.08I |
315 |
7/8" - 14 |
1/2" - 14 |
37,5 |
38 |
14 |
12,5 |
24 |
|
292.10.12I |
160 |
7/8" - 14 |
3/4" - 14 |
37,5 |
41,5 |
15,5 |
12,5 |
24 |
|
292.12.12I |
160 |
1 1/16" - 12 |
3/4" - 14 |
42 |
41,5 |
15,5 |
15,5 |
24 |
|
292.12.16I |
160 |
1 1/16" - 12 |
1" - 11,5 |
45 |
50 |
24 |
16 |
33 |
|
292.16.12I |
160 |
1 5/16" - 12 |
3/4" - 14 |
46 |
45 |
18 |
22 |
33 |
|
292.16.16I |
160 |
1 5/16" - 12 |
1" - 11,5 |
49 |
50 |
21 |
22 |
33 |
|
292.20.16I |
160 |
1 5/8" - 12 |
1" - 11,5 |
52 |
60 |
24 |
28 |
41 |
|
292.20.20I |
160 |
1 5/8" - 12 |
1 1/4" - 11,5 |
52 |
61 |
32 |
28 |
45 |
|
292.24.24I |
140 |
1 7/8" - 12 |
1 1/2" - 11,5 |
64 |
59 |
33 |
33 |
50 |
GOMITO A 90° MASCHIO JIC 37° - MASCHIO NPT - Aertubi
GOMITO A 90° MASCHIO JIC 37° - MASCHIO NPT
