NIPPLO MASCHIO RIDOTTO - INTERMEDIO DIRITTO BSPP

Code

Code

Codice

Code

Código

Pressure

Druck

Pressione

Pression

Presión

F=BSPP

Thread • Gewinde

Filetto • Filetage

Rosca

F1=BSPP

Thread • Gewinde

Filetto • Filetage

Rosca

L

L1

L2

D

D1

Ch

103.4.2I

400

1/4" - 19

1/8" - 28

28

10

8

6

4,5

19

103.6.2I

400

3/8" - 19

1/8" - 28

30,5

12

8

9

4,5

22

103.6.4I

400

3/8" - 19

1/4" - 19

33

12

10

9

6

22

103.8.4I

400

1/2" - 14

1/4" - 19

38,5

14

10

13

6

27

103.8.6I

400

1/2" - 14

3/8" - 19

40

14

12

13

9

27

103.10.6I

400

5/8" - 14

3/8" - 19

39,6

16

14

14,5

11,5

30

103.10.8I

400

5/8" - 14

1/2" - 14

42

16

14

14,5

11,5

30

103.12.6I

400

3/4" - 14

3/8" - 19

41

16

12

17,5

9

32

103.12.8I

400

3/4" - 14

1/2" - 14

45

16

14

18,5

13

32

103.12.10I

400

3/4" - 14

5/8" - 14

45

16

16

17

14,5

32

103.16.6I

400

1" - 11

3/8" - 19

47

18

12

23

9

41

103.16.8I

400

1" - 11

1/2" - 14

48

18

14

23,5

13

41

103.16.12I

400

1" - 11

3/4" - 14

51

18

16

23

17

41

103.20.12I

200

1 1/4" - 11

3/4" - 14

53,5

20

16

30,5

17

50

103.20.16I

200

1 1/4" - 11

1" - 11

56

20

18

30

23

50

103.24.16I

200

1 1/2" - 11

1" - 11

57

22

18

37

23

55

103.24.20I

200

1 1/2" - 11

1 1/4" - 11

60

22

20

37

30

55

103.32.16I

100

2" - 11

1" - 11

57

22

18

45

23

70

103.32.20I

100

2" - 11

1 1/4" - 11

59

22

20

45

30

70

103.32.24I

100

2" - 11

1 1/2" - 11

61

22

22

45

37

70

103.40.32I

65

2 1/2" - 11

2" - 11

70

26

25

57

45

90
